B-70264EN/02 1.NOTES ON USE
- 7 -
1.5 POWER CABLE
(1) If placing the cable in the duct
If laying the power cable by placing it in the duct between the
power board and the laser oscillator, use a single-core cable. For
the C4000-E, run the 3-phase cable through the conduit (cable
clamp) and the ground wire through the signal line inlet when
introducing the oscillator.
C1000-E
OSC Recommendation
Hitachi Cable : 600V MLFC
Cross Section
22mm
2
73A
Diameter
φ
10.3mm
Max Current
LAPP : Multi standard single core
25mm
2
φ
10.1mm 78A
C2000-E
C4000-E
C5000-E
C6000-E
Type Layout
Single Core
4 pieces
Cross Section
Diameter
Furukawa : 600V LMFC 22mm
2
φ
10.3mm 73A
Hitachi Cable : 600V MLFC 50mm
2
124A
φ
14.4mm
LAPP : Multi standard single core
50mm
2
φ
14mm 120A
Furukawa : 600V LMFC 50mm
2
φ
14.4mm 124A
Hitachi Cable : 600V MLFC 100mm
2
205A
φ
20.3mm
LAPP : Multi standard single core
120mm
2
φ
19.4mm 209A
Furukawa : 600V LMFC 100mm
2
φ
20.3mm 205A
Hitachi : 600V MLFC 150mm
2
250A
φ
22.2mm
Furukawa : 600V LMFC 150mm
2
φ
22.2mm
250A
Hitachi Cable : 600V MLFC 200mm
2
304A
φ
26.9mm
Furukawa : 600V LMFC 200mm
2
φ
26.9mm
304A
Single Core
3 pieces
Single Core
4 pieces
Diameter
Cross Section
Diameter
Cross Section
(2) If not placing the cable in the duct
If not placing the power cable in the duct between the power
board and the laser oscillator, you can use a heavy-duty power
cord cable.
C1000-E
OSC Recommendation
Hitachi Cable : 600V 2PNCT
Cross Section
22mm
2
89A
Diameter
φ
28mm
Max Current
LAPP : OLFLEX 100 25mm
2
φ
25.4mm
93A
C2000-E
Hitachi Cable : 600V 2PNCT 38mm
2
124A
φ
34mm
LAPP : OLFLEX 100 50mm
2
φ34.5mm
146A
C4000-E
LAPP : OLFLEX 100 95mm
2
φ
41.3mm
217A
C5000-E
Hitachi Cable : 600V 2PNCT 100mm
2
253A
φ
24mm
LAPP : OLFLEX FD-90 120mm
2
φ
23.8mm
219A
C6000-E
Hitachi Cable : 600V 2PNCT 125mm
2
291A
φ
26mm
LAPP : OLFLEX FD-90 185mm
2
φ28.9mm
285A
4 Core
Sheathed
Portable
1 piece
Cross Section Diameter
Type Layout
3 Core
Sheathed
Portable
1 piece
Cross Section
Diamete
r
1 Core
Sheathed
Portable
4 pieces
Cross Section
Diameter
