Additional Manual
Edit Date Design Contents
Title
of
Drawin
Drawing
No.
FANUC Series 16/160i-LA/LB
Automatic aging function setting screen
Specification
A-79279E
Page
2 / 7
Recog
nition
Newly designed
Suzuki
Tokito
04.01.05 01
Item #1 corrected.
Suzuki
Tokito
04.09.29 03
A
ll revised.
Suzuki
Tokito
05.03.25 04
1. Outline
A setting screen has been added, which can show all the setting values for automatic aging
function. You can see and change all the setting values for aging function and power calibration
in this new setting screen.
2. Specification
This setting screen consists of three pages. Page 1 and Page 2 are for aging function. Page 3 is for
power calibration.
2.1. Automatic aging function setting screen
You can display the setting screen with the method as follows.
(1) Push the MDI key ‘OFFSET’ several times for displaying the laser setting screen.
(2) Push the soft key [SET].
(3) Push the soft key [AGING], and you can see the automatic aging function setting screen.
2.2. Contents of screen
POWER SET DATA 3D.TRN
SET TRACE W-AXIS AGING
Operation of soft key：Automatic Aging function setting screen
AGING FUNCTION
[AGING SETTING 1]
AGING (0:OFF,1:ON) = *
REMAINING CYCLES = ***
YEAR DATA = ****
MONTH DATA = ****
DAY DATA = ****
HOUR DATA = ****
TIME LEFT = **** MIN.
MANUAL MODE(0:OFF,1:ON) = *
SET MANUAL TIMES = ***
Page 1.
No.15008#6
No.15334
No.15335
No.15336
No.15337
No.15338
No.15340
Parameter number
