FANUC Series 16/160i-LA/LB Automatic Aging Function Setting Screen, Specification Additional Manual Page 4
Additional Manual
Edit Date Design Contents
Title
of
Drawin
Drawing
No.
FANUC Series 16/160i-LA/LB
Automatic aging function setting screen
Specification
A-79279E
Page
4 / 7
Recog
nition
Newly designed
Suzuki
Tokito
04.01.05 01
Item #1 corrected.
Suzuki
Tokito
04.09.29 03
A
ll revised.
Suzuki
Tokito
05.03.25 04
This setting is determined by timing of RUN-ON. Thus the action of aging
function does not change if this setting is changed when aging function is
executed.
Parameter
－
Setting value 0 or 1
Name SET MANUAL TIMES
Meaning You can set the aging execution times when you start the aging function by
manual operation. When parameter No.15014#4=0, only the setting value "2" is
set in this item. When parameter No.15014#4=1, the value from 2 to 255 can be
set in this item.
Parameter
Ｎｏ．１５３４０
Setting range
２~２５５
The items displayed in page 2 are shown as follows. A setting range in the following explanation is a
setting range to input on this screen.
Name POWER
Meaning Laser output power for aging function.
Parameter
Ｎｏ．１５３２６
Setting range
０～９９９９
Name FREQUENCY
Meaning Laser output frequency for aging function.
Parameter
Ｎｏ．１５３２７
Setting range
０～２０００
Name DUTY
Meaning Laser output duty for aging function.
Parameter
Ｎｏ．１５３２８
Setting range
０～１００
Page 2
No.15326
No.15327
No.15328
No.15329
No.15330
No.15331
No.15339
Parameter Number
AGING FUNCTION
[AGING SETTING 2]
POWER = **** W
FREQUENCY = **** HZ
DUTY = *** %
CAL. TIME = ***** S
GAS PRESS.(50Hz) = *****
GAS PRESS.(60Hz) = *****
INTERVAL = ***** H
