Operation manual of FS30i
PC tool for Memory Card Program
Operation/Editing
Feb 18.2004
O1
G91 X10. Y10.
M30
O10
G91 X10. Y10.
M30
%
O1
G91 X10. Y10.
M30
%
O1
G91 X10. Y10.
M30
A
vailable for Drop-in
Unavailable for Drop-in
Example of Program
<O1>
G91 X10. Y10.
M30
Note
1 If the same named program file exists, another
same named program file cannot be dropped in.
2 If free space on the memory card program file is
lacking, new program file cannot be dropped in.
3 If the NC program name is not compliant with
"Naming rules of Program file", the program file can
not be dropped in.
If the File name acts as Program number, "O" is displayed on the first
row of list view.
- Drop-out from List view window
Drop-out from list view of this PC tool to Explorer is available.
Note
Do not drop out to Work folder. If dropped out to
Work folder, this PC tool cannot continue to
function normally.
Previous page
Next page
