Series 30i/31i/32i -MODEL A Additional Manual Page 17

Additional Manual
A-79353E
Title
Draw
No.
17/20
Sheet
Operation manual of FS30i/31i/32i-MODEL A
PC tool for Memory Card Program
Operation/Editing
Ed. Date Design Description
Date Desig. Apprv.
Feb 18.2004
1.3 Rules of characters in Program file
Outlines
Words in parentheses "( )" in Program file are treated as comments.
The mark of comment start "(" is named "Control-out".
The mark of comment end ")" is named "Control-in".
"Control-out" and "Control-in" must make a pair. The order is 1st -
"Control-out" and 2nd -"Control-in". And nested parentheses is not
available.
Note
1 1. When a program file is dropped in, space code
(0x20 SPC) , tab code (0x09 HT) , carriage return
code(0x0d CR) and percent code(0x25 %) is
deleted. If "%" is found in Control-in, characters
between "%" and next "LF" (0x0a) is deleted.
2 The front of program number ":" is changed to
"O"(O as in Oscar) while the program file dropped
in.
3 The program file can only have one NC program.
Usable characters in Control-in
List of ANSI(ASCII) codes of usable characters(hexadecimal form)
Code Character Code Character Code Character Code Character
0a LF 3f ? 58 X 74 t
23 # 40 @ 59 Y 75 u
26 & 41 A 5a Z 76 v
28 ( 42 B 5b [ 77 w
29 ) 43 C 5d ] 78 x
2a * 44 D 5f _ 79 y
2b + 45 E 61 a 7a z
2c , 46 F 62 b
2d - 47 G 63 c
2e . 48 H 64 d
2f / 49 I 65 e
30 0 4a J 66 f
31 1 4b K 67 g
32 2 4c L 68 h
33 3 4d M 69 i
34 4 4e N 6a j
35 5 4f O 6b k
36 6 50 P 6c l
37 7 51 Q 6d m
38 8 52 R 6e n
39 9 53 S 6f o
3a : 54 T 70 p
