Series 0i - MA Operators manual Page 724

Operators manual

Page of 751

/ 751

APPENDIXG. ALARM LIST

B–63514EN/01

700

Number ContentsMessage

155 ILLEGAL T–CODE IN M06 In the machining program, M06 and T code in the same block do not

correspond to the group in use. Correct the program.

156 P/L COMMAND NOT FOUND P and L commands are missing at the head of program in which the

tool group is set. Correct the program.

157 TOO MANY TOOL GROUPS The number of tool groups to be set exceeds the maximum allowable

value. See parameter GS1, GS2 (No. 6800 bit 0 and 1). Modify the

program.

158 ILLEGAL TOOL LIFE DATA The tool life to be set is too excessive. Modify the setting value.

159 TOOL DATA SETTING INCOM-

PLETE

During executing a life data setting program, power was turned off.

Set again.

175 ILLEGAL G107 COMMAND Conditions when performing cylindrical interpolation start or cancel

not correct. To change the mode to the cylindrical interpolation

mode, specify the command in a format of “G07.1 rotation–axis name

radius of cylinder.”

176 IMPROPER G–CODE IN G107 Any of the following G codes which cannot be specified in the cylin-

drical interpolation mode was specified.

1) G codes for positioning, such as G28,, G73, G74, G76, G81 – G89,

including the codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G52,G92,

3) G code for selecting coordinate system: G53 G54–G59

Modify the program.

190 ILLEGAL AXIS SELECT In the constant surface speed control, the axis specification is wrong.

(See parameter No. 3770.) The specified axis command (P) contains

an illegal value.

Correct the program.

194 SPINDLE COMMAND IN SYN-

CHRO–MODE

A contour control mode, spindle positioning (Cs–axis control) mode,

or rigid tapping mode was specified during the serial spindle

synchronous control mode. Correct the program so that the serial

spindle synchronous control mode is released in advance.

197 C–AXIS COMMANDED IN SPINDLE

MODE

The program specified a movement along the Cs–axis when the sig-

nal CON(DGN=G027#7) was off. Correct the program, or consult the

PMC ladder diagram to find the reason the signal is not turned on.

199 MACRO WORD UNDEFINED Undefined macro word was used. Modify the custom macro.

200 ILLEGAL S CODE COMMAND In the rigid tap, an S value is out of the range or is not specified.

The maximum value for S which can be specified in rigid tapping is

set in parameter (No.5241 to 5243). Change the setting in the

parameter or modify the program.

201 FEEDRATE NOT FOUND IN RIGID

TAP

In the rigid tapping, no F value is specified.

Correct the program.

202 POSITION LSI OVERFLOW In the rigid tapping, spindle distribution value is too large.

203 PROGRAM MISS AT RIGID

TAPPING

In the rigid tapping, position for a rigid M code (M29) or an S

command is incorrect. Modify the program.

204 ILLEGAL AXIS OPERATION In the rigid tapping, an axis movement is specified between the rigid

M code (M29) block and G84 (G74) block. Modify the program.

205 RIGID MODE DI SIGNAL OFF Rigid tapping signal (DGNG 061#1) is not 1 when G84 (G74) is

executed though the rigid M code (M29) is specified.Consult the PMC

ladder diagram to find the reason the DI signal is not turned on.

Modify the program.

206 CAN NOT CHANGE PLANE (RIGID

TAP)

Plane changeover was instructed in the rigid mode.

Correct the program.

207 RIGID DATA MISMATCH The specified distance was too short or too long in rigid tapping.

210 CAN NOT COMAND M198/M99 M198 and M99 are executed in the schedule operation. Or M198 is

executed in the DNC operation.
