Notice of the revision of Digital Servo ROM 90A7 series Additional Manual Page 5

Additional Manual
Title 9083 / 9087 / 90A3 / 90A7
Learning Control Operator’s Manual
03 '00.06.07 N.Sonoda Qualified 2'nd issue Draw No.
02 ’99.01.14 K.Maeda Qualified 1’st issue
A - 63639E - 034
01 ’97.12.08 K.Maeda Newly designed Sheet 03
Edit Date Design Description / 070
1. Overview
This manual describes the only special servo functions and parameters relating to High-speed Cutting and
Learning function used in FANUC Digital AC Servo. With respect to the information of the standard servo
function for general cutting tools, you can get it from FANUC AC SERVO MOTOR
α series PARAMETER
MANUAL B65150E.
• High-speed Cutting means "High-speed Cycle Cutting" on NC memory or “DNC operation” by Personal
Computer through HSSB, or “Data Server Operation” with High-speed binary operation.
• Learning function works only during G05 execution, which is High-speed cutting in the part program.
• As you can set Learning function for each axis, you can mix Leaning axes and Normal axes.
Major specification of Learning control
• Command period Max. 32sec (C-axis minimum speed 1.875min
-1
for Cam application)
• Pulse distribution period Min. 0.5msec (for αL6 or αL9 etc, the other is 1msec ∗1)
• Frequency Band Max. 500Hz (for αL6 or αL9 etc, the other 200Hz ∗1)
• Profile number Max. 16 profiles (Cam grinder)
• Learning step number Max. 5 steps (Cam grinder)
Note ∗1) Refer to “Appendix 3 Parameter table for Learning control”. The item of “velocity” and “FBND” is Min.
distribution period and Max. Frequency Band in the order. Remark is important for the application.
The parameters for High-speed Cutting tools different from those for general cutting tools are described in
5.3 Servo parameters list and explained in 5.4 Parameter details.
• For the other standard Servo parameters described in this manual and adjustments, refer to
"FANUC AC Servo Motor α series Parameter Manual" B-65150E.
Servo ROM series for High-speed Cutting tools and for general cutting tools are listed as follows.
Table 1-1. Combinations of Servo Software Series and CNC type
For general cutting tools
For High-speed cutting tools
Servo CNC
Servo CNC
9030 Series 0-C
Series 15-A
9033 Series 0-C
(Series 15-A)
9050
9060
Series 16-A, 18-A
Series 15-B
9053 Series 16-A
9070 Series 16-B, 18-B
Series 15-B
9073 Series 16-B, 18-B
Series 16-C, 18-C
9080
Series 16-C, 18-C
Series 15-B
9083
9087
Series 16-B, 18-B
Series 16-C, 18-C
9090 Series 16i-A,
Series 18i-A
90A0 Series 16i-A,
Series 18i-A
90A3
90A7
Series 16i-A,
Series 18i-A
