AC Spindle Motor Beta i Descriptions Page 21

Descriptions
B-65312EN/01 MOTOR TYPES AND USAGE 2.NOTES ON INSTALLATION
- 7 -
6 Dynamic balance
During high-speed operation, a small imbalance may cause a
large vibration, resulting in an unusual sound, premature bearing
damage, or some other abnormality.
Therefore, reduce the amount of the imbalance with the dynamic
balance of the other rotation shafts, as well as the gear and
pulley mounted on the output shaft of the motor, as much as
possible.
- Balance correction
With the βi series, a shaft with no key is used as standard to
facilitate the balance correction of a pulley, gear, and
coupling attached to the shaft. Use a completely symmetric
pulley, gear, or coupling, and use a backlash-less tightening
part such as a SPANN ELEMENTE to secure a pulley, gear,
or coupling to the shaft. When attaching a pulley to a shaft,
for example, adjust the periphery vibration to within 20 µm.
This basically eliminates the need for balance correction.
To further reduce the vibration level, make a field balance
correction, for example, by tightening a screw into the
tapped hole for balance correction provided on a
component such as a pulley.
NOTE
When a shaft with a key is required, contact your
FANUC sales representative.
