Analog Input Separate Detector Interface Unit Additional Manual Page 9
Additional Manual
Title
Sheet
Draw. No.
A
nalog input
separate detector interface unit
9/18
FANUC LTD
A-56731E-0099
Description Desig. Date Edit.
01 050714 Matsukane
9. Connection with the encoder with analog 1Vp-p interface
Shield drain
1
A
2
XA
3
B
4
XB
11
12
0V
13
14
0V
5
Z
6
XZ
7
8
15
16
0V
17
18
+5V
9
+5V
19
JF111～JF114
(PCR-EV20MDT)
10
20
+5V
Analog input separate detector interface unit
Shield
Ground plate
Cable specification
Encoder with analog interface
1
2
A
XA
A
XA
3
4
B
XB
B
XB
5
6
Z
XZ
Z
XZ
9
18
+5V
+5V
+5V
+5V
20
12
+5V
0V
+5V
0V
14
16
0V
0V
0V
FG
Recommended cable
A66L-0001-0286 (#20AWG*6 + #24AWG*3pairs)
Recommended connector
PCR-E20FA(Honda Tsusin Kogyo)
FI30-20S（Hirose Electric）
FCN-247J020-G/E(Fujitsu)
52622-2011(Molex)
FI40B-2015S(Hirose electric)
NC(ADIF)
NC(BDIF)
NC(T0)
NC(PZ)
No connection to “NC” pins
(Frame ground)
NOTE
The +5V lines above can be used for the power supply to
the encoders. The supply current per encoder is 0.35
A
maximum.
Minimum tolerance of +5V: 4.95V
