FANUC Series 30i
TILTED WORKING PLANE COMMAND
The enhancement in tool axis direction command
A
- 79449
2002.02.20
T.Sasaki
10
/
12
S.Ide
1.1.1 Parameters
#7 #6 #5 #4 #3 #2 #1 #0
19608 PRI
[Input type] Parameter input
[Data type] Bit path
# 5 PRI Among multiple end point candidates that exist when a movement is
made for a rotation axis by a command of tool center point control for
5-axis machining (type 2) or tilted working plane command:
0: A combination in which the master (first rotation axis) makes a
smaller angular movement is selected for a machine of tool rotation
type or table rotation type. A combination in which the table (second
rotation axis) makes a smaller angular movement is selected for a
machine of mixed type.
1: A combination in which the slave (second rotation axis) makes a
smaller angular movement is selected for a machine of tool rotation
type or table rotation type. A combination in which the tool (first
rotation axis) makes a smaller angular movement is selected for a
machine of mixed type.
19741 Upper limit of the movement range of the first rotation axis
[Input type] Parameter input
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data]Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
(When the increment system is IS-B, -999999.999 to +999999.999)
In tool center point control for 5-axis machining (type 2) or tilted
working plane command, set the upper limit of the movement range of
the first rotation axis. When the movement range of the first rotation
axis is not specified, this parameter and parameter No. 19742 must both
be set to 0.
