Series 0i - Model A Connection manual (Hardware) Page 271

Connection manual (Hardware)
Index
B–63503EN/02
i–1
[Symbols]
+24V Input Power Specifications, 33
[Numbers]
20–pin Interface Connectors and Cables, 228
9″ CRT Display Unit Interface, 46
[A]
Action Against Noise, 13
Address Assignment by Ladder, 171
Adjusting the 10.4″ Color LCD, 50
Adjusting the 7.2″ Monochrome LCD, 49
Adjusting the 8.4″ Color LCD, 48
Analog Spindle Interface, 74
Attaching a CRT Protective Cover, 257
[B]
Battery, 40
Battery for Memory Backup (3VDC), 40
Battery for Separate Absolute Pulse Coders (6VDC),
42
Board–mounted Connectors, 229
Built–in I/O Card Connection, 90
[C]
Cable Clamp and Shield Processing, 20
Cable Connectors, 230
Cable for Power Supply to Control Unit, 39
Cable Lead–in Diagram, 24
Cable Length When Only One Manual Pulse Genera-
tor is Used, 71
Configuration, 1
Connecting DI/DO, 92
Connecting I/O Devices, 57, 58
Connecting Machine Interface I/O, 87
Connecting the FANUC Servo Unit β Series with I/O
Link, 169
Connecting the Manual Pulse Generator, 69
Connecting the signal ground (SG) of the control unit,
16
Connection, 110, 170
Connection Cable (Supplied from US), 243
Connection Diagram, 177
Connection of Battery for Separate Type Absolute
Detector, 80
Connection of FANUC I/O Link by Electric Cable,
112
Connection of MDI Unit, 51
Connection of Operator’s Panel I/O Module (for Ma-
trix Input), 136
Connection to CNC Peripherals, 43
Connection to Display Unit, 45
Connection to FANUC I/O Link, 108
Connection to Machine Operator’s Panel, 114
Connection to Manual Pulse Generators, 70
Connection to the Display Unit, 44
Connection to the High–speed Skip (HDI), 106
Connection to the MDI Unit, 51
Connection to the Operator’s Panel I/O Module, 153
Connection to the Standard MDI Unit, 52
Connections, 116
Connector (on the cable side) specifications, 123
Connector Layout Diagram, 26
Connector Locations of Main Panel B, 126
Connector Pin Arrangement, 91
Control Unit, 23
Cooling by Heat Exchanger, 11
[D]
Design and Installation Conditions of the Machine
Tool Magnetic Cabinet, 9
Detachable key top, 132
DI (General–purpose Input Signal) Connection, 139,
156
DI (input signal) connection, 120
DI (Matrix Input Signal) Connection, 141
DI Signals and Receivers, 89
DI/DO Address, 124
DI/DO Connector Pin Arrangement, 138, 155
DI/DO Mapping, 126
DO (Output Signal) Connection, 142, 160
DO (output signal) connection, 122
DO Signals and Drivers, 89
[E]
Emergency Stop Signal, 172
