2.2. Waiting function between 2 paths
Waiting function between 2 pathsWaiting function between 2 paths
Waiting function between 2 paths
In mode-1, non-cylindrical grinding are executed by both grinding heads.
The rotary axes for workpiece, C,A axes, exist in path 1, so binary data for path 1 must be
programmed.
Further more, workpice must be rotated synchronous with the binary programming for path 2
because non-cylindrical grinding is also executedin path 2.
This function enables the waiting between G05 blocks of both paths and to start the binary
operation at the same time simultaneously
㧔
Programming format
㧕
G05 P9;
Note: The “G05P9” block should not be commanded except for mode-1.
O1000;
G05 P9;
(Binary)
:
M99;
%
O2000;
G05 P9;
(Binary)
:
M99;
%
(Binary programming for path 1 )
(Binary programming for path 2 )
Starting simultaneously
after waiting
Previous page
Next page
