  2. Machine Operator's Panel Interface Unit (with 3-MPG interfaces) A-73282E/01

Machine Operator's Panel Interface Unit (with 3-MPG interfaces) A-73282E/01 Additional Manual Page 6

Additional Manual
76543210
DI+00 FUSE
DI+01 KY07 KY06 KY05 KY04 KY03 KY02 KY01 KY00
DI+02 KY17 KY16 KY15 KY14 KY13 KY12 KY11 KY10
DI+03 KY27 KY26 KY25 KY24 KY23 KY22 KY21 KY20
DI+04 KY37 KY36 KY35 KY34 KY33 KY32 KY31 KY30
DI+05 KY47 KY46 KY45 KY44 KY43 KY42 KY41 KY40
DI+06 KY57 KY56 KY55 KY54 KY53 KY52 KY51 KY50
DI+07 KY67 KY66 KY65 KY64 KY63 KY62 KY61 KY60
DI+08 KY77 KY76 KY75 KY74 KY73 KY72 KY71 KY70
DI+09 DI07 DI06 DI05 DI04 DI03 DI02 DI01 DI00
DI+10 DI17 DI16 DI15 DI14 DI13 DI12 DI11 DI10
DI+11 DI27 DI26 DI25 DI24 DI23 DI22 DI21 DI20
DI+12 DI37 DI36 DI35 DI34 DI33 DI32 DI31 DI30
DI+13 LM07 LM06 LM05 LM04 LM03
DI+14 SM07 SM06 SM05 SM04 SM03
DI+15 MP17 MP16 MP15 MP14 MP13 MP12 MP11 MP10
DI+16 MP27 MP26 MP25 MP24 MP23 MP22 MP21 MP20
DI+17 MP37 MP36 MP35 MP34 MP33 MP32 MP31 MP30
DI+18 KY87 KY86 KY85 KY84 KY83 KY82 KY81 KY80
DI+19 KY97 KY96 KY95 KY94 KY93 KY92 KY91 KY90
DI+20 KYA7 KYA6 KYA5 KYA4 KYA3 KYA2 KYA1 KYA0
DI+21 KYB7 KYB6 KYB5 KYB4 KYB3 KYB2 KYB1 KYB0
DO+0 MD07 MD06
DO+0 L1L7 L1L6 L1L5 L1L4 L1L3 L1L2 L1L1 L1L0
DO+0 L2L7 L2L6 L2L5 L2L4 L2L3 L2L2 L2L1 L2L0
DO+0 L3L7 L3L6 L3L5 L3L4 L3L3 L3L2 L3L1 L3L0
DO+0 L4L7 L4L6 L4L5 L4L4 L4L3 L4L2 L4L1 L4L0
DO+0 L1H7 L1H6 L1H5 L1H4 L1H3 L1H2 L1H1 L1H0
DO+0 L2H7 L2H6 L2H5 L2H4 L2H3 L2H2 L2H1 L2H0
DO+0 L3H7 L3H6 L3H5 L3H4 L3H3 L3H2 L3H1 L3H0
DO+0 L4H7 L4H6 L4H5 L4H4 L4H3 L4H2 L4H1 L4H0
DO+0 DO07 DO06 DO05 DO04 DO03 DO02 DO01 DO00
DO+1 DO17 DO16 DO15 DO14 DO13 DO12 DO11 DO10
DO+1 DO27 DO26 DO25 DO24 DO23 DO22 DO21 DO20
DO+1 DO37 DO36 DO35 DO34 DO33 DO32 DO31 DO30
FUSE ： When 1, it indicates the +5E fuse has blown.
Shorting of the general-purpose DI input is considered as a possible cause. Turn off the power at once, check
the general-purpose DI input and its vicinity, replace the fuse and turn the power on.
DInx ： General-purpose DI
LM0x ： Load meter indication
SM0x ： Speed meter indication
KYnx ： Key signal (matrix)
LnL(H)x ： LED signal（matrix）
DOnx ： General-purpose DO
MD07 ： Buzzer mode selection（It is possible to sound the key entry confirmation tone at the matrix DI input by
turning this to "1"）
MD06 ： Buzzer ON/OFF setting (The buzzer sounds as this is turned to "1" and stops as it is turned to "0".
This operation is performed irrespective of MD07.)
MPnx ：Manual pulse generator
EDIT.
FANUC LTD
SHEET
DRAW. NO. CUST.
TITLE
005/
DESCRIPTIONDESIG.DATE
Ａ－７３２８２Ｅ／０１
PMC
A
DDRES
BIT NUMBER
Scope in which PMC
addresses can be used
I/O Link allocation
128/128 256/256
3-4.PMC Addresses
Previous page
Next page
