Fanuc Power Mate i Supplement to Manual Page 4

Supplement to Manual
(2) Multi path mode
Path 1 (X, Y, Z-axis): use the signals of PMC axis group “A”
Feedrate override signal: *FV0E-*FV7E(G151)
Override cancel signal: OVCE(G150.5)
Path 2 (U, V axis): use the signals of PMC axis group “D”
Feedrate override signal: *FV0ED-*FV7ED(G187)
Override cancel signal: OVCED(G186.5)
Path 3 (W axis): use the signals of PMC axis group “F”
Feedrate override signal: *FV0EF-*FV7EF(G485)
Override cancel signal: OVCEF(G484.5)
PMC axis
A axis: use the signals of PMC axis group “G”
Feedrate override signal: *FV0EG-*FV7EG(G497)
Override cancel signal: OVCEG(G496.5)
B axis: use the signals of PMC axis group “H”
Feedrate override signal: *FV0EH-*FV7EH(G509)
Override cancel signal: OVCEG(G508.5)
< In case the feedrate override signals are assigned to those of CNC axis commonly, and the
override cancel signal is assigned to the signals for each PMC axis group >
[Setting parameters]
Parameter OVE(PRM8001#2)=0 (The feedrate override signals for PMC axis are assigned to
those of CNC axis commonly), parameter IOVC(8009#0)=1, INOV (8009#1)=0
[Assignment of feedrate override signals and override cancel signals]
(1) Single path mode
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVC(G006.4)
(2) Multi path mode
Path 1 (X, Y, Z axis): use the signals of PMC axis group “A”
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVCE(G150.5)
Path 2 (U, V axis): use the signals of PMC axis group “D”
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVCED(G186.5)
Path 3 (W axis): use the signals of PMC axis group “F”
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVCEF(G484.5)
PMC axis
A axis: use the signals of PMC axis group “G”
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVCEG(G496.5)
B axis: use the signals of PMC axis group “H”
Feedrate override signal: *FV0-*FV7(G012)
Override cancel signal: OVCEG(G508.5)
A-78898
4/7
EDIT
DATE DESIG. DESCRIPTION
FANUC Power Mate i – MODEL D/H
PMC axis control – Feedrate override and Feedrate
override cancel for each axis group Specifications
TITLE
DRAW.NO. CUST.
SHEET
