Fanuc Power Mate i Supplement to Manual Page 7

Supplement to Manual
4.2 Signal address
#7 #6 #5 #4 #3 #2 #1 #0
G150 OVCE
G151
*FV7E *FV6E *FV5E *FV4E *FV3E *FV2E *FV1E *FV0E
G162
OVCEB
G163
*FV7EB *FV6EB *FV5EB *FV4EB *FV3EB *FV2EB *FV1EB *FV0EB
G174
OVCEC
G175
*FV7EC *FV6EC *FV5EC *FV4EC *FV3EC *FV2EC *FV1EC *FV0EC
G186
OVCED
G187
*FV7ED *FV6ED *FV5ED *FV4ED *FV3ED *FV2ED *FV1ED *FV0ED
G472
OVCEE
G473
*FV7EE *FV6EE *FV5EE *FV4EE *FV3EE *FV2EE *FV1EE *FV0EE
G484
OVCEF
G485
*FV7EF *FV6EF *FV5EF *FV4EF *FV3EF *FV2EF *FV1EF *FV0EF
G496
OVCEG
G497
*FV7EG *FV6EG *FV5EG *FV4EG *FV3EG *FV2EG *FV1EG *FV0EG
G508
OVCEH
G509
*FV7EH *FV6EH *FV5EH *FV4EH *FV3EH *FV2EH *FV1EH *FV0EH
A-78898
7/7
EDIT
DATE DESIG. DESCRIPTION
FANUC Power Mate i – MODEL D/H
PMC axis control – Feedrate override and Feedrate
override cancel for each axis group Specifications
TITLE
DRAW.NO. CUST.
SHEET
