Fanuc Power Mate i Supplement to Manual Page 5

Supplement to Manual
3. Parameter
[Data type] Bit
IOVC: In case of PMC axis control, override cancel is
0: specified by one common signal for all PMC axis groups.
It depends on the value of parameter OVE(8001#2) which signals
are used
1: specified by each signal for each PMC axis group.
INOV: In PMC axis control, feedrate override is
0: specified by one common signal for all axis groups.
It depends on the value of parameter OVE(8001#2) which signals
are used
1: specified by each signal for each PMC axis group.
#7 #6 #5 #4 #3 #2 #1 #0
8009 INOV IOVC
Note
1. In case that one common feedrate override signal and one common
override cancel signal are used commonly for all axis group b
y
setting “0” to both above parameter IOVC(8009#0) and INOV(8009#1),
the address of the common signal is decided by the paramete
r
OVE(8001#2) as follows:
In case of the parameter OVE(8001#2)=0,
Override cancel signal: G006.4
Feedrate override signal: G012
In case of the parameter OVE(8001#2)=1,
Override cancel signal: G150.5
Feedrate override signal: G151
2. Only in case of the parameter IOVC(8009#0)=0 or INOV(8009#1)=0,
OVE(8001#2) is effective.
In case of the parameter IOVC(8009#0)=1 and INOV(8009#1)=0,
Override cancel signal: specified by each signal for each PMC
axis group.
Feedrate override signal: specified by one common signal fo
r
all axis groups. It depends on the
value of parameter OVE(8001#2)
which signals are used.
A-78898
5/7
EDIT
DATE DESIG. DESCRIPTION
FANUC Power Mate i – MODEL D/H
PMC axis control – Feedrate override and Feedrate
override cancel for each axis group Specifications
TITLE
DRAW.NO. CUST.
SHEET
