FANUC Series 30i-MODEL A
ACTIVE OFFSET VALUE CHANGE
FUNCTION BASED ON MANUAL FEED
Jan.06.’04
New design
8/22
Signal
Active offset value change mode signal CHGAO<Gn297#4>
[Classification] Input signal
[Function] Selects the active offset value change mode based on manual feed.
[Operation] If all of the following conditions are satisfied, the active offset value change mode
based on manual feed is set by setting this signal to 1:
・The automatic operation halt state or automatic operation stop state is set (with
STL<F000#4> set to 0).
・The manual handle feed mode, incremental feed mode, jog feed mode is selected.
If a movement on an axis is made by manual handle feed, incremental feed, or jog
feed in this mode, the offset value currently valid among the offset values
selected with the active offset selection signals AOFS1 and AOFS2 <G297#5 and
#6> is changed by the travel distance moved on the axis.
By setting bit 5 (APL) of parameter No. 3115 to 1, the relative position indication
(counter) can be preset to 0 when the active offset value change mode is selected
with this signal. In this case, a changed offset value can be restored to the
original value by returning by manual feed to the position represented by a
relative position indication (counter) of 0.
Active offset selection signal AOFS1<Gn297#5>、AOFS2<Gn297#6>
[Classification] Input signal
[Function] Selects a type of offset value to be changed in active offset value change operation
based on manual feed.
[Operation] From tool length compensation value, cutter compensation value, and workpiece
origin offset, choose a type of offset value to be changed by active offset value
change operation based on manual feed according to the table below.
AOFS2 AOFS1 Offset value to be changed
0 0 Tool length compensation value
0 1 Cutter compensation value
1 0 Workpiece origin offset
Active offset value change in-progress signal MCHAO<Fn297#5>
[Classification] Output signal
[Function] Posts that the active offset value change mode based on manual feed is selected
and an offset value is being changed.
[Output condition] When all of the following conditions are satisfied, this signal is set to 1:
・The active offset value change mode signal CHGAO <Gn297#4> is set to 1.
・The automatic operation halt state or automatic operation stop state is set (with
STL<F000#4> set to 0).
