Series 30i-MODEL A, ACTIVE OFFSET VALUE CHANGE FUNCTION BASED ON MANUAL FEED Additional Manual Page 15

Additional Manual
A-79341E
Title
Draw
No.
Ed. Date Design Description
Date
Jan.06.’04 Design. Apprv.
page
FANUC Series 30i-MODEL A
ACTIVE OFFSET VALUE CHANGE
FUNCTION BASED ON MANUAL FEED
Jan.06.’04
New design
13/22
NOTE
To change the tool offset value for the Y-axis, the option for Y-axis offset is
required.
・Changing a tool offset value
The tool offset value with the offset number corresponding to an T code specified in
automatic operation is changed. If there is no currently valid tool offset value as in a case
where no T code is specified after a cycle start, tool offset value change is made even when a
movement is made on an axis by manual feed.
By making a movement on a basic axis (X, Z, or Y), a tool offset value change can be made.
With a movement on a rotation axis, no tool offset value change can be made. While a tool
offset value is being changed, a movement by manual feed can be made on one axis only.
Example
・Specified T code: T0110
・Value set with offset number 10: 54.700 mm
・Travel distance on the Z-axis by manual feed: -2.583 mm
In this example, the Z-axis value for tool offset value number 10 is:
54.700+(-2.583) = 52.117 mm
NOTE
A changed tool offset value is handled according to bit 6 (EVO) of
parameter No. 5001 and bit 6 (AON) of parameter No. 5041.
・Changing a workpiece origin offset value
The workpiece origin offset of the workpiece coordinate system corresponding to a G code
from G54 to G59 or from G54.1 P1 to P48 (300) specified during automatic operation is
changed on an axis-by-axis basis. A valid workpiece coordinate system exists at all times.
So, when a movement is made on an axis by manual feed, the workpiece origin offset of the
workpiece coordinate system is changed without fail. This change can be made by a
movement on an arbitrary axis, which may be a linear axis or a rotation axis. While a
workpiece origin offset change is being made, movements can be made on multiple axes by
manual feed.
Example
・Specified workpiece coordinate system：G56
・Workpiece origin offset of G56 (X axis)： 50.000
・Workpiece origin offset of G56 (Z axis)： 5.000
・Workpiece origin offset of G56 (C axis)： 180.000
・Workpiece origin offset of G56 (Y axis)： -60.000
・Travel distance on the X axis by manual feed： -10.000mm
・Travel distance on the Z axis by manual feed： 10.000mm
・Travel distance on the C axis by manual feed： 90.000deg
・Travel distance on the Y axis b
y
manual feed： -5.000mm
