Series 30i-MODEL A, ACTIVE OFFSET VALUE CHANGE FUNCTION BASED ON MANUAL FEED Additional Manual Page 17

Additional Manual
A-79341E
Title
Draw
No.
Ed. Date Design Description
Date
Jan.06.’04 Design. Apprv.
page
FANUC Series 30i-MODEL A
ACTIVE OFFSET VALUE CHANGE
FUNCTION BASED ON MANUAL FEED
Jan.06.’04
New design
15/22
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3115 APL
[Input type] Parameter input
[Data type] Bit axis
# 5 APL When the active offset value change mode based on manual feed is selected, the
relative position indication is automatically:
0: Not preset.
1: Preset.
This parameter is used to restore an offset value changed in the active offset value change
mode to the original value. An offset value can be restored to the original value by making
a movement on the axis by manual feed so that the relative position indication (counter) is set
to a position of 0.
#7 #6 #5 #4 #3 #2 #1 #0
5000 ASG
[Input type] Parameter input
[Data type] Bit
# 4 ASG When the tool geometry compensation function and tool wear compensation
function are enabled, the offset value to be changed by the function is:
0: Geometry compensation value
1: Wear compensation value
#7 #6 #5 #4 #3 #2 #1 #0
5040 MOF
[Input type] Parameter input
[Data type] Bit
# 2 MOF As the DI/DO signals for the active offset value change function based on manual
feed:
0: G297#4, G297#5, G297#6, and F297#5 are used.
1: G203#4, G203#5, G203#6, and F199#5 are used.
