FANUC Series 30i-MODEL A
ACTIVE OFFSET VALUE CHANGE
FUNCTION BASED ON MANUAL FEED
Jan.06.’04
New design
7/22
#7 #6 #5 #4 #3 #2 #1 #0
5041 AON ACR
[Input type] Parameter input
[Data type] Bit path
# 0 ACR If the active offset value change mode based on manual feed is selected in the
reset state or clear state, the tool length compensation value/cutter compensation
value:
0: Can be changed.
1: Cannot be changed.
In the clear state (with bit 6 (CLR) of parameter No. 3402 set to 1), whether the
tool length compensation value/cutter compensation value is changeable depends
on the setting of bit 7 (CFH) of parameter No. 3409 as indicated below.
Parameter ACR=0 Parameter ACR=1
Parameter CFH=0
Not changeable Not changeable
Parameter CFH=1
Changeable Not changeable
# 6 AON If a tool length compensation value change is made with the active offset value
change function based on manual feed in tool length compensation A or tool
length compensation B:
0: The change becomes valid in the next block where a G43, G44, or H code is specified.
1: The change becomes valid in the next buffered block.
NOTE
1 This parameter is valid when bit 6 (EVO) of parameter No. 5001 is set to
0.
2 If this parameter is set to 1, a changed compensation value may be
modified by input through the MDI keys or a G10 command before the
compensation value becomes valid. Even in such a case, the operation
of this parameter remains valid.
3 If this parameter is set to 1, a reset operation may be performed before
the changed compensation value becomes valid. In such a case, the
operation of this parameter becomes invalid.
