FANUC Series 30i-MODEL A
ACTIVE OFFSET VALUE CHANGE
FUNCTION BASED ON MANUAL FEED
Jan.06.’04
New design
4/22
workpiece origin offset change is being made, movements can be made on multiple axes by
manual feed.
Example
・Specified workpiece coordinate system：G56
・Workpiece origin offset of G56 (X axis)： 50.000
・Workpiece origin offset of G56 (Y axis)： -60.000
・Workpiece origin offset of G56 (Z axis)： 5.000
・Workpiece origin offset of G56 (A axis)： 5.000
・Workpiece origin offset of G56 (B axis)： 15.000
・Travel distance on the X axis by manual feed： -10.000mm
・Travel distance on the Y axis by manual feed： -5.000mm
・Travel distance on the Z axis by manual feed： 10.000mm
・Travel distance on the A axis by manual feed： 8.000mm
・Travel distance on the B axis by manual feed： -2.000mm
In this example, the workpiece origin offsets of G56 are as follows:
・X axis : 50.000+(-10.000) = 40.000
・Y axis : -60.000+(-5.000) = -65.000
・Z axis : 5.000+10.000 = 15.000
・A axis : 5.000+8.000 = 13.000
・B axis : 15.000+(-2.000) = 13.000
・Operation depending on each tool offset memory
Offset value change operation varies according to tool offset memory A/B/C as follows:
Tool offset
memory
Changed offset value
A
No distinction is made between a tool length compensation
value and cutter compensation value.
The value specified with the offset number corresponding to
the currently valid H code or D code is changed.
B
No distinction is made between a tool length compensation
value and cutter compensation value.
The value specified with the offset number corresponding to
the currently valid H code or D code is changed.
Depending on the setting of bit 4 (ASG) of parameter No.
5000, a geometry compensation value or wear compensation
value is changed.
C
The tool length compensation value and cutter compensation
value specified with the offset numbers corresponding to the
currently valid H code and D code are changed.
Depending on the setting of bit 4 (ASG) of parameter No.
5000, a geometry compensation value or wear compensation
value is changed.
Previous page
Next page
