5. Diagnoses
954 Gas pressure in leak check mode 1
st
(Pchk1)
955 Gas pressure in leak check mode 2
nd
(Pchk2)
956 Gas pressure in leak check mode 3
rd
(Pchk3)
957 Gas pressure in leak check mode 4
th
(Pchk4)
Laser gas pressure is logged in DGN954 at 30 seconds passed since all valves
shut. And from DGN955 to DGN957 are logged at 1/3-leak judgement
time(PRM.15154) intervals.
These data are kept even if CNC is power-off.
6. Limitation and notes
i) Automatic leak check function does not work when level 1 laser alarm occurs.
Automatic leak check function works when level 2 laser alarm occurs.
7. Applicable series
Applied version of each series are as follows.
Model Series Leak check screen Other Leak check screen Note
B801
─ ─
FS16-LA
B802
─ ─
FS16-LB B8A1
─
20
th
FS16-LCB B815
─
8
th
B8F1
─
13
th
FS16i-LA
B8F3
─
2
nd
FS16i-LPA
B8F5
─
5
th
FS16i-LB
B8H1 7
th
1
st
FS16i-LPB
B8H5 2
nd
1
st
note )
The leak check screen might be displayed by the old versions not
applied.
However, correct data might not be displayed in old versions.
Please use this function after confirming the above-mentioned
number of versions.
