FS 16i/18i/21i Additional Manual Page 11

Additional Manual
11/11
A- 77987EN
DRAW.No.
FANUC Series 16
i
/18
i
/21
i
Specifications of Distance Coded Linear
Scale Interface Ex
p
ansion
Title
Newly Registered
DESCRIPTIONDESIGNE
99.12.03
DATE
01
EDIT.
2.3 Notes
(1) PMC axis control
The reference point establishment operation is not executed by the rapid traverse (axis
control command 00h) and the JOG feed (axis control command 06h) of PMC axis control.
(2) Rapid traverse operation by command other than G00
The reference point establishment operation is not executed by the rapid traverse
operation automatically generated with the command in the fixed cycle, etc.
(3) Reference point establishment operation
The specification of reference point establishment by detecting some reference marks is
compatible with the past one. The limitations and parameter setting method etc. are also
the same as past specifications. Please refer to "FANUC Series 16/18/16i/18i/21i distance
coded linear scale interface specifications (A-61209)" for details.
3. Parameters
Data type : Bit axis type
DG0x The reference point establishment operation by the G00 command and
JOG feed is
0 : Not applied.
1 : Applied.
1818
DG0x
#7
#6
#5 #4 #3 #2 #1 #0
