FS 16i/18i/21i Additional Manual Page 8

Additional Manual
8/11
A- 77987EN
DRAW.No.
FANUC Series 16
i
/18
i
/21
i
Specifications of Distance Coded Linear
Scale Interface Ex
p
ansion
Title
Newly Registered
DESCRIPTIONDESIGNE
99.12.03
DATE
01
EDIT.
2.1.2.4 Stopping by feed hold
The operation becomes a non linear positioning when execution is restarted after the feed
hold during the reference point establishment operation. And the reference point
establishment operation is not restated in this block. The reference point establishment
operation is executed again by the next G00 command.
2.1.2.5 Stopping by reset or emergency stop
When reset or the emergency stop is applied in the reference point establishment operation,
the reference point establishment operation is stopped. The reference point establishment
operation is executed again by the next G00 command.
2.1.2.6 Detection of illegal reference mark interval
When the interval of the reference mark cannot be correctly detected by some causes, the
axis is positioned in the end point without establishing the reference point. That is, the
machine position of the end point, the absolute coordinate value, and the machine
coordinates value become as well as the case to execute the usual G00 operation which the
reference point establishment operation is not executed. However, the tool path becomes a
result different from the case to execute usual G00 operation. The reference point
establishment operation is executed again by the next G00 command.
Even if the interval of the illegal reference marks is detected, the P/S090 alarm is not
generated.
