C. BOOT SYSTEM
121
When SYTEM DATA LOADING is selected, the file selection screen
below appears. The name of a file on the memory card is displayed by
pressing the <±> or <°> key on the DPL. When the name of the desired
file is displayed, press <INPUT> to start loading the file.
LOADING MENU
*881GA_B.MEM
: File selection screen
During the loading, the screen below is displayed.
881GA_B.MEM
LOADING
: The name of the file that is being loaded
is displayed, and the indication
LOADING blinks.
The file selection screen appears again upon the completion of the
loading. To close the file selection screen, press <INPUT> with *END
displayed on the screen, to return to the initial screen. The operator can
also return to the initial screen by simply pressing <CAN>.
When SYTEM DATA CHECK is selected, the file information screen
below appears. The information about another file can be displayed by
pressing the <±> or <°> key on the DPL.
CHECK MENU
1 NC BASIC(10)
: File information screen
The parenthesized value indicates the
number of management units used (1
unit: 128 KB).
When the name of the desired file is displayed, press <INPUT> to display
the detailed information (series, ROM number, edition, and internal
management number (16 max.)) about the file as shown below.
NC BASIC
1 881G 801A 00
: Detailed file information screen
To close the detailed file information screen, press <INPUT> with *END
displayed on the screen, to return to the file information screen. The
operator can also return to the file information screen by simply pressing
<CAN>. To return from the file information screen to the initial screen,
press <INPUT> with *END displayed on the file information screen. The
operator can also return to the initial screen by simply pressing <CAN>.
C.2.1
SYSTEM DATA
LOADING Screen
D Operating procedure
(DPL/MDI)
C.2.2
SYSTEM DATA CHECK
Screen
D Operating procedure
(DPL/MDI)
