DIGITAL SERVO ADAPTER Maintenance manual Page 167

Maintenance manual
B–63465EN/01
F. SETTING/DISPLAY/MAINTENANCE
USING THE MAIN UNIT OF
THE Digital Servo Adapter
APPENDIX
151
(1)Do not change the rotary switch position during the above setting
operation; otherwise, the Digital Servo Adapter operation becomes
unstable.
(2)When the 7–segment LED blinks at low–speed, the frequency is 0.5
Hz. When the LED blinks at high–speed, the frequency is 2 Hz.
(3)When an undefined number is specified with the rotary switch, the
system assumes that 0 has been specified. However, since undefined
numbers are reserved for future function expansion, do not use
undefined numbers.
(4)When data is saved in and restored from a memory card in a batch, the
data is treated as follows:
Table F.4.1 Data in the Digital Servo Adapter
Data type Data Size File name
Save/
restoration
allowed/
not allowed
SRAM SRAM data
About 0.256 MB SRAM256A.FDB Allowed
0.52 MB for each SRAM1_0A.FDB
SRAM1_0B.FDB
Allowed
(5)Do not remove or insert the memory card during batch save and
restoration operation.
