DIGITAL SERVO ADAPTER Maintenance manual Page 86

Maintenance manual
3. INPUT AND OUTPUT OF DATA
B–63465EN/01
70
1. Set emergency stop.
2. Press the
key to display the settings screen.
3. Use the cursor keys to position the cursor at PWE, then press the
key and the key, in that order, to enable parameters to be written.
The Digital Servo Adapter will generate P/S alarm 100.
4. Press the
key several time to display the parameter screen.
> &0001 00000000
&0002 00000000
5. Move the cursor to the number of the parameter to change.
Method 1
Use the cursor keys. The cursor will continue to move while a cursor
key is being pressed.
Method 2
Press the following keys and enter data in the order shown :
[(parameter No.)]
6. Enter a parameter value with the data input keys.
7. Press the
key. The parameter value is input and displayed.
8. After all parameters have been set and confirmed, retum to the settings
screen and set PWE to 0.
9. Normally, in order to release the alarm state, press the
key.
However, in order to release alarm No. 000, the power needs to be
turned off and then on again.
3.1
SETTING
PARAMETERS
PROCEDARE
(DPL/MDI)
