DIGITAL SERVO ADAPTER Maintenance manual Page 67

Maintenance manual
B–63465EN/01
2. HARDWARE
51
WARNING
Before replacing a blown fuse, it is necessary to remove the
cause of the blown fuse. For this reason, only the personnel
who have a working knowledge of maintenance and safety
are allowed to carry out this work. When replacing a fuse
with the cabinet open, be careful not to touch the
high–voltage circuit section (marked and shielded with
a shock hazard prevention cover). If you touch the
high–voltage circuit section when it is uncovered, you will
get an electric shock.
This section describes the replacement of the Digital Servo Adapter
controller fuse.
This section applies to the Digital Servo Adapter controller.
The Digital Servo Adapter control unit is equipped with a 24 VDC power
input fuse (FUS1). If the fuse has blown, LEDM2 (red LED) lights
provided that 24 VDC is supplied to the control unit.
While referring to Section 2.6.1, pull out the base printed–circuit board,
and replace the fuse on the base printed–circuit board. The fuse is located
beside the power connectors CP1 and CP2.
Table 2.7.1 Capacity and part number of controller fuse
Name Capacity Part number
FUS1 5.0A A02B–0124–K101
CAUTION
When the fuse is replaced, it is necessary to pull out the
base printed–circuit board a little. Observe the CAUTION
described in Section 2.6.1.
2.7
REPLACING THE
FUSE
2.7.1
The Controller Fuse
