Series 0i/0i Mate - Model B Descriptions Page 360

Descriptions
B. FUNCTIONS AND TAPE FORMAT LIST
B–63832EN/01
APPENDIX
336
Some functions cannot be added as options depending on the model.
In the tables below,
P
I
:presents a combination of arbitrary axis
addresses using X,Y,Z,A,B and C (such as X_Y_Z_A_).
x = 1st basic axis (X usually)
y = 2nd basic axis (Y usually)
z = 3rd basic axis (Z usually)
Functions Illustration Tape format
G00 _ ;
G01 _ F_;
(x, y)
G03(x, y)
G17
G02
G03
X_ Y_
R_
I_ J_
F_ ;
G18
G02
G03
X_ Z_
R_
I_ K_
F_ ;
G19
G02
G03
Y_ Z_
R_
J_ K_
F_ ;
G04
X_
;
Start point
Start point
Positioning (G00)
Linear interpolation (G01)
Circular interpolation
(G02, G03)
Dwell (G04)
P_
J
R
I
G02
Start point
Start point
R
I
J
IP
IP
IP
IP
(1/6)
(x, y)
(xyz)
z
Helical interpolation
(G02, G03)
Start
point
When G03 is specified for
the XY plane
G17
G02
G03
X_ Y_
R_
I_ J_
a_F_ ;
G18
G02
G03
X_ Z_
R_
I_ K_
a_F_ ;
G19
G02
G03
Y_ Z_
R_
J_ K_
a_F_ ;
a: Any address other than that of
a circular interpolation axis
Cylindrical interpolation
(G07.1)
G07.1 IP_R_ ;
Cylindrical interpolation mode
R : Radius of cylinder
G07.1 IP 0 ;
Cylindrical interpolation mode cancel
B.2
M SERIES
Previous page
Next page
