To Meet the Requirement of the EMC Directive Additional Manual Page 43

Additional Manual
A-72937EN/11
To meet the requirement of the EMC Directive
TMN06007E_A-72937EN_11.DOC
- 41 -
Annex 1 : Change of FANUC products in relation with the EMC Directive
The following products were revised to conform to the EMC directive in 1995.
Power supply unit for CNCs
No. Product remarks
1 Power supply unit AI
2 Power supply unit BI
3 Power supply unit of 0-C that meets CE requirements
Display unit, MDI unit
No. Product remarks
4
Units that use 9.5
”LCD(TFT type)unit
5
Units that use 8.4
”LCD(TFT type)unit
6 Units that use display device other than above two
7 MDI unit
8 Machine operator’s panels
9 Handy type operator’s unit for Power Mate-D/H
10 DPL/MDI unit for Power Mate-F/D/H/E
CNC PCBs
No. Product remarks
11 Memory card for 0-C
12 Axis card of 0-C
13 Multi-axis card for 0-C
14 Servo PCB of Power Mate-E
15 Integrated I/O card D of Power Mate-F
16 Base PCB of Power Mate-D
17 Base PCB of Power Mate-F
Servo motor, servo amplifier, spindle amplifier
No. Product remarks
18
Integrated
α pulse coders in servo motors
19
α Power supply module (PSM)
20
α Servo Module (SVM)
21
α Spindle Module (SPM)
22 Servo Unit (SVU, SVUC)
Note) There is no change in spindle motors.
Previous page
Next page
