To meet the requirement of the EMC Directive
TMN06007E_A-72937EN_11.DOC
- 43 -
Clause
4.3.1
Cable application Cable specification Grounding
condition *)
Attachment of
Ferrite core
(7)
Cable for Manual Pulse Generator Overall shield cable
(8)
Ethernet cable
Twisted pair cable (STP cable)
with a common shield in category 5
(9)
USB cable
USB compatible cable
with a common shield
Near the
cable inlet of
cabinet in
which CNC
installed
------
With punch panel
Near the
punch panel
Near NC and
punch panel
Except for i series
At the both
ends
(10)
Serial port
cable
(RS232C,
RS422)
Without
punch panel
i series CNC
At the both
ends
------
(11)
Feedback cable
for Stand-alone type Pulse Coder
At the both
ends
Analog spindle input
of
i series
Near the NC
(12)
Position coder
cable
(13) Analog I/O cable
Near the
cable inlet of
cabinet in
which CNC
installed
(14) I/O link cable
Overall shield pair wire cable
At the both
ends
(15) DI/DO cable (DC24V, AC voltage)
(16) Relay output c
able
Overall shield cable
Near the
cable inlet of
cabinet in
which CNC
installed
(17) Communication cable for I/O unit Model B
Overall shield twisted pair wire
cable
At the both
ends
(18) Input power cable Cabtyre cable ------
------
Note *
)
It is important for external cable grounding to be close to the cable inlet.
