FANUC Series 16i/18i/21i-MB, Active Block Cancel Function, Specifications Additional Manual Page 9

Additional Manual
Ed.
ApprovalCharge
Page
Name
9/9
Date
2002.4.25
Contents
Making
FANUC Series 16i/18i/21i-MB
Active Block Cancel Function
A-78889EN
Nagano
Draw
Signal Address
#7 #6 #5 #4 #3 #2 #1 #0
G297 BCAN
F297 MBCAN
Note
⋅ Please confirm neither the tool route nor work piece interfere when
the operation is restarted.
⋅ When an automatic operation is restarted, the route of an actual
movement is different from an original route because it is a start
from the canceled position. Therefore, there is a possibility that the
tool route and the work piece interfere when restarting. Please note
that these do not interfere enough when restarting.
⋅ If inputting reset or the emergency stops while stopping by this
function, this function becomes invalid. In a word, maintained
various data and modalities are changed to clearness or the state of
reset by the reset operation.
⋅ This function is effective only while automatic operation. (OP=1
and STL=1)
⋅ If the part program is incremental instruction, the terminal of the
next block shifts cancellation amount when automatic operation
restarts. This amount of the gap keeps remaining until the absolute
instruction is executed next. Therefore, this function cannot be used
to check the block terminal by the program made by the incremental
instruction.
⋅ This function is not available during high precision contour control
mode (HPCC), AI high precision contour control mode (AI HPCC),
AI nano high precision contour control mode (NANO HP). Even if
the cancel signal is input, it is ignored.
