MACRO COMPILER for 30i-A Operators manual Page 18

Operators manual
3.SYSTEM INSTALLATION (SETUP) B-66264EN/01
- 10 -
3.4 COMPILER SERIES
There are four types of FANUC Macro Compiler systems. One type is
for
FANUC Series 30i. The other three types are provided for the
systems shown below.
<1> For FANUC Series 0/Series 16/Series 18/Series 20/Series 21
<2> FANUC Series 15-A/15-B
<3> FANUC Series 15i-A
These Compiler systems are for the respective series only. Compiling
the same macro program using these compiler systems generates
different object codes. For this reason, be sure to use the execution
files (macro compiler/linker/memory card converter) and library files
suitable to the development model.
If multiple systems are to be installed on the same personal computer,
it is recommended that a separate directory be used for each CNC
series.
For the FANUC Macro Compiler system for FANUC Series
0/15/16/18/20/21, see the FANUC MACRO COMPILER
PROGRAMMING MANUAL (B-66102E).
CNC series Macro compiler Macro linker
Memory card
format converter
30i
MCOMP30I MLINK30I MCARD30I
0/16/18/20/21
MCOMP0 MMCARD
15-A/15-B
MCOMP15
MLINK
MMCARD15
15i-A
MCOMP15I MLINK15I MCARD15I
* This manual provides information only on Series 30i.
