D.2.3 SYSTEM DATA DELETE Screen
Description
This screen is used to delete a user file from Flash ROM or Memory
card.
Screen configuration
(1)
(2)
(3)
(4)
(5)
(1) Screen title.
(2) Select the FROM SYSTEM screen.
(3) Select the MEMORY CARD SYSTEM
screen.
(4) Returning to the MAIN MENU.
(5) Message
Screen configuration (FROM SYSTEM screen)
(1)
(2)
(3)
(4)
(1) Screen title.
(2) Names of files in Flash ROM
The number of management units
constituting each file appears in
parentheses to the right of the filename.
(3) Returning to the MAIN MENU.
(4) Message
SYSTEM DATA DELETE
1.FROM SYSTEM
2.MEMORY CARD SYSTEM
3.END
*** MESSAGE ***
SELECT MENU AND HIT SELECT KEY.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
SYSTEM DATA DELETE
FROM DIRECTORY
1 NC BAS-1(0008)
2 NC BAS-2(0008)
3 NC BAS-3(0008)
4 NC BAS-4(0008)
5 DGD0SRVO(0003)
6 PS0B (0006)
7 PMC1 (0001)
8 END
*** MESSAGE ***
SELECT FILE AND HIT SELECT KEY.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
