4.6 High Speed Serial Bus (HSSB)
HSSB Interface Board PANEL i
( CNC side)
Optical Fiber Cable
COP 7
(for 150i/160i/180i/210i) COP7 (for 150i/160i/180i/210i)
COP21 (for 300i) COP21 (for 300i)
1) RECOMMENDED CABLE（Optical Fiber Cable）
A66L-6001-0026#L1R003・・・Cable Length = 1 m
A66L-6001-0026#L3R003・・・Cable Length = 3 m
A66L-6001-0026#L5R003・・・Cable Length = 5 m
A66L-6001-0026#L7R003・・・Cable Length = 7 m
A66L-6001-0026#L10R03・・・Cable Length = 10 m
A66L-6001-0026#L15R03・・・Cable Length = 15 m
A66L-6001-0026#L20R03・・・Cable Length = 20 m
A66L-6001-0026#L30R03・・・Cable Length = 30 m
A66L-6001-0026#L40R03・・・Cable Length = 40 m
A66L-6001-0026#L50R03・・・Cable Length = 50 m
A66L-6001-0026#L100R3・・・Cable Length = 100m
(only for 150i/160i/180i/210i)
Use the following cable and a relay connector when an optical cable is relayed with the relay adapter
and it wants to use it.
2) Low-loss optical fiber cable for junction only
A66L-6001-0029#L1R003・・・Cable Length = 1 m
A66L-6001-0029#L3R003・・・Cable Length = 3 m
A66L-6001-0029#L5R003・・・Cable Length = 5 m
A66L-6001-0029#L7R003・・・Cable Length = 7 m
A66L-6001-0029#L10R03・・・Cable Length = 10 m
A66L-6001-0029#L15R03・・・Cable Length = 15 m
A66L-6001-0029#L20R03・・・Cable Length = 20 m
A66L-6001-0029#L30R03・・・Cable Length = 30 m
A66L-6001-0029#L40R03・・・Cable Length = 40 m
A66L-6001-0029#L50R03・・・Cable Length = 50 m
Note) Total cable length is less than 35m incase of 300i
3) Low-loss optical junction adapter
A63L-0020-0004
Optical fiber cable used for FANUC I/O Link, for FSSB inside wiring
and for Serial Spindle can not be used
Optical fiber cable can not be cut or joined by customer.
Use one of above cables.
(4)
(5)
(5)
(5)
04
Comment “inside wiring”
is added.
05 PANEL i for 300i is added
