FANUC PANEL i Additional Manual Page 25

Additional Manual
Connecting Manual
For FANUC PANEL i
EDIT
DRAW. NO. CUST
TITLE
DESCRIPTION
DESIG.
DATE
A
-83125E
25
/
SHEET
4.12 Video Port
PANEL i (Ex.) Monitor
JA63
（PCR-EV20MDT） (Dsub 15 pin)
1) RECOMMENDED CABLE MATERIAL SPEC.
A66L-0001-0371・・・coaxial 5 core （in case that the above ( ) signals are not needed）
2) RECOMMENDED CONNECTOR FOR CABLE and HOUSING (JD63 side）
CONNECTOR HOUSING MAKER
FI40B-20S FI-20-CV5/6 (Hirose Electric)
3) NOTE
① It is not necessary to change any setting parameter for enable this port.
② The recommended cable length is up to 2m when the external monitor is connected to this port
directly with the above recommended cables.
In case that the distance between the monitor and PANEL i is longer, please use the video
extender in the market. (For example CAT5 KVM Extender made by Black Box Corp.)
In that case, the cable length should be as short as possible between PANEL i and video
extender.
③ Necessary specifications for select the video extender is as follows,
Interface : Analog RGB
Resolution : XGA (1024x768 dot)
Vertical refresh rate : 60 Hz
④ The screen quality of the external monitor is influenced by performance of the monitor, stability
of the power supply, quality of the video cable and environmental conditions. Please check
enough those point.
⑤ The power of the extender and monitor should be supplied from other than PANEL i.
⑥ The monitor side figure shows a sample interface. Design the cable to suit the interface of the
actual device to be connected. Especially pay attention to the signals attached ( ). One monitor
needs these ( ) signal, and the other monitor does not need them.
⑦ The CRT output resolution is as same as the resolution of LCD. The CRT output resolution of
10.4” LCD type is 640x480, that of 12.1” LCD type is 800x600 and that of 15.0” LCD type is
1024x768.
1 RED 11 (PU_1)
2 0V 12 VS
3 GREEN 13 0V
4 0V 14 0V
5 BLUE 15 (+5V)
6 0V 16 0V
7 0V 17 (+5V)
8 (DDA) 18 HS
9 0V 19 (SENCE)
10 (DCK) 20 0V
1 RED
2 GREEN
3 BLUE
4 (PU_1)
5 0V
6 0V
7 0V
8 0V
9 (+5V)
10 0V
11
(SENCE)
12 (DDA)
13 HS
14 VS
15 (DCK)
(3)
03
Marked (3)’s are added and modified
(3)
(4)
04 Note (7) is added.
