D OPTICAL FIBER CABLE
The Series 15i/150i uses optical fiber cables for the following interfaces.
This table lists the usable combinations.
Interface Junction
Recommended
optical cable
Maximum
allowable
transmission
distance
Junction adapter
none A66L-6001-0026#L~ 100m
Serial spindle interface
*1
exist A66L-6001-0029#L~ 55m *2 A63L-0020-0004
none A66L-6001-0026#L~ 200m
I/O Link interface
*1
exist A66L-6001-0026#L~ 100m *2 A63L-0020-0002
none A66L-6001-0026#L~ 100m
High speed serial bus
(HSSB)
interface
exist A66L-6001-0029#L~ 55m
*2 A63L-0020-0004
none A66L-6001-0023#L~ 10m
Serial servo bus (FSSB)
interface
none A66L-6001-0026#L~ 100m
none A66L-6001-0026#L~ 100m
CNC–Display unit
interface
exist A66L-6001-0029#L~ 55m *2 A63L-0020-0004
*Note)
1. When an optical fiber cable is used for connection.
2. Only one relay point is permitted. And you can relay two optical fiber cables
on condition that the sum of the line length of two cables is within the range of the
maximum allowable transmission distance or less.
