4. DESCRIPTION OF PARAMETERS
155
#7
SOF8301
#6 #5
SYE
#4
SYA
#3 #2 #1 #0
[Data type] Bit
SYA In the servo–off state in simple synchronous control, the limit of the
difference between the positioning deviation of the master axis and that of
the slave axis is:
0 : Not checked.
1 : Checked.
SYE During execution of synchronization, the limit of the difference between
positioning deviations (parameter No. 8313 or 8323) is:
0 : Checked.
1 : Not checked.
SOF The synchronization funciton in simple synchronous control (one pair) is:
0 : Not used.
1 : Used.
#7
SMA8302
#6 #5 #4 #3
SSE
#2 #1
ATS
#0
ATE
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
ATE Automatic setting of grid positioning for simplified synchronous control
one pair is:
0 : Disabled
1 : Enabled
ATS Automatic setting of grid positioning for simplified synchronous control
one pair is:
0 : Not started
1 : Started
NOTE
1 When the bits are set to 1, parameter No.8316 and bit 4
(APZx) of parameter No.1815 for the master and slave axes
are set to 0.
2 These bits are automatically set to 0 once grid positioning
has been completed.
SSE In simple synchronization control, the external machine coordinate
system shift function for the slave axis is:
0 : Not used.
1 : Used.
For axes under simple synchronization control, when the external
machine coordinate system shift is performed for the master axis, it can
also performed for the slave axis simultaneously.
4.31
PARAMETERS OF
SIMPLE
SYNCHRONOUS
CONTROL
