Series 0i-PC Parameter manual Page 171

Parameter manual
B–64160EN/01
4. DESCRIPTION OF PARAMETERS
163
8130 Number of total controlled axes
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Byte
[Valid data range] 2 to 4
Set the total number of CNC controlled axes.
#7
8131
#6 #5 #4 #3
AOV
#2
EDC
#1 #0
HPG
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
HPG Manual handle feed is
0 : Not used.
1 : Used.
EDC External deceleration is
0 : Not used.
1 : Used.
AOV Automatic corner override is
0 : Not used.
1 : Used.
#7
8132
#6 #5
SCL
#4 #3 #2
BCD
#1 #0
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
BCD Second auxiliary function is
0 : Not used.
1 : Used.
SCL Scaling is
0 : Not used.
1 : Used.
4.33
PARAMETERS OF
FS0i BASIC
FUNCTIONS
