FANUC Series 16i /18i /21i Additional Manual Page 11

Additional Manual
Edit
Apprv.Desig.
Sheet
Title
Draw
No.
11
/
11
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–MB/TB
Automatic operation and temporary
storage of external program
ith M l M
A-79189EN
03.Sep.’03
Data No. Data
12017
M code for registering part program into temporary storage memory
Data type Word
Valid data
range
1-999
This parameter sets the M code which instructs to register part program
into temporary storage memory. If the parameter is set to 0, M298 is
used.
Data No. Data
12018
M code for program registration completion waiting
Data type Word
Valid data
range
1-999
This parameter sets the M code which instructs to wait program
registration completion. If the parameter is set to 0, M297 is used.
Data No. Data
12019
M code for deleting program on temporary storage memory
Data type Word
Valid data
range
1-999
This parameter sets the M code which instructs to delete program on
temporary storage memory. If the parameter is set to 0, M296 is used.
