FANUC MODBUS/TCP Additional Manual Page 49

Additional Manual
A-90188E-01 CONNECTION 3.HARDWARE CONNECTIONS
- 47 -
3.4.2 Cable Materials
CAUTION
Unshielded cable (UTP cable) is commercially
available as 100BASE-TX twisted-pair cable: You
should, however, use shielded Category 5
twisted-pair cable (STP cable) to improve the
resistance to electrical noise in an FA environment.
Recommended Cables
Manufacturer Specification Remarks
Furukawa Electric Co., Ltd. DTS5087C-4P Twisted-pair cable
Nissei Electric Co., Ltd. F-4PFWMF Single-conductor cable
Inquiries
Manufacturer Contact address
Furukawa Electric Co.,Ltd.
Sales Headquarters
2-6-1 Marunouchi, Chiyoda-ku. Tokyo 100-8322
TEL: 03-3286-3126 FAX: 03-3286-3979
Remark
Nissei Electric Co., Ltd.
Machida Branch
3F MU Bldg., 1-9-1 Minami-narise, Machida City,
Tokyo 194-0045
TEL: 0427-29-2531 FAX: 0427-29-3375
Overseas Sales Office IWATANI International Corporation
Tokyo Head Office
21-8 Nishi-shinbashi 3-chome, Minato-ku,
TOKYO, 105-8458, JAPAN
TEL: 03-5405-5810 FAX: 03-5405-5666
Telex: 2524256 IWATYO J
Remark
A
finished cable with connectors at both ends
can be offered.
NOTE
The recommended cables cannot be connected to
moving parts.
