Manual Guide (for Milling) Operators manual Page 56

Operators manual
3. PROGRAMMING OPERATIONS
OPERATION B-63424EN/03
-44-
By pushing [DETAIL], the following pop-up window is
displayed.
CHORD
LENGTH
: Input the chord length of an arc.
Straight-line distance from the start point of an
arc to its end point
TANGENT
ANGLE
: Input the angle of an inclination of the straight
line which is tangent to the circle to be defined,
at the start point of the arc.
After inputting the necessary data, by pushing a INSERT, a pop-up
windows is closed and inputted data are displayed in a program
window as the following ISO code program.
NOTE
After calculating intersections, the address only is
displayed in the case that the data is not defined.
CHORD LENGTH L=
TANGENT ANGLE A=
CCW ARC
(
DETAIL
)
G103 X Y R I J B E V W M N K Q (L A ) ;
In
p
utted data
Center
p
oint
(
X
,
Y
)
Radius of arc
End
p
oint
(
X
,
Y
)
G code for contour CCW arc
Previous page
Next page
