Function name Applicability
Learning function Y
Look–ahead repetition control Y
Polygon between spindles Y
Abnormal load detect function f
Chuck/tailstock barrier Y
PMC axis control velocity command function Y
Corner rounding f
Butt–type reference position setting f
Circular threading Y
Tandem control f
C executor + macro executor f
Motor velocity signal output f
Additional C executor memory f
Two Floppy Cassette control f
Main CPU custom software capacity f
Sub CPU custom software capacity f
Straightness compensation f
Simple spindle synchronization f
Stroke limit check before movement Y
Manual linear/circular interpolation f
Three/four spindle serial outputs f
Third/fourth spindle orientation f
Third/fourth spindle output selection f
Controlled axis count specification (sub side) f
Controlled axis expansion f
Controlled axis count specification f
Simultaneous controlled axis expansion f
Axis control by PMC Y (*1)
Increment system 1/10 f
Linear acceleration/deceleration after cutting feed in-
terpolation
f
Axis removal f
Feedrate second override f
