APPENDIXG. ALARM LIST

B–63524EN/01

866

6) Over travel alamrs

Number Message Contents

500 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side stored stroke limit I.

(Parameter No.1320 or 1326 NOTE)

501 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side stored stroke limit I.

(Parameter No.1321 or 1327 NOTE)

502 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side stored stroke limit II.

(Parameter No.1322 )

503 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side stored stroke limit II.

(Parameter No.1323)

504 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side stored stroke limit III.

(Parameter No.1324 )

505 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side stored stroke limit III.

(Parameter No.1325 )

506 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side hardware OT.

507 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side hardware OT.

508 INTERFERENCE : +n When n–axis is moving in the positive direction, it interferes with the

order tool post (only with two–path control)

509 INTERFERENCE : –n When n–axis is moving in the negative direction, it interferes with the

order tool post (only with two–path control)

510 OVER TRAVEL : +n A stroke limit check, made before starting movement, found that the

end point of a block falls within the plus (+) side inhibited area along

the n–axis defined by a stroke limit. Correct the program.

511 OVER TRAVEL : –n A stroke limit check, made before starting movement, found that the

end point of a block falls within the minus (–) side inhibited area along

the N–axis defined by a stroke limit. Correct the program.

NOTE

Over travel alarms No. 504 and No. 505 are provided only with the T series.

Parameters 1326 and 1327 are effective when EXLM(stroke limit switch signal) is on.

7) Overheat alarms

Number Message Contents

700 OVERHEAT: CONTROL UNIT Control unit overheat

Check that the fan motor operates normally, and clean the air filter.

701 OVERHEAT: FAN MOTOR The fan motor on the top of the cabinet for the control unit is over-

heated. Check the operation of the fan motor and replace the motor if

necessary.

704 OVERHEAT: SPINDLE Spindle overheat in the spindle fluctuation detection

(1)If the cutting load is heavy, relieve the cutting condition.

(2)Check whether the cutting tool is share.

(3)Another possible cause is a faulty spindle amp.

8) Rigid tapping alarm

Number Message Contents

740 RIGID TAP ALARM : EXCESS

ERROR

During rigid tapping, the position deviation of the spindle in the stop

state exceeded the setting.

741 RIGID TAP ALARM : EXCESS

ERROR

During rigid tapping, the position deviation of the spindle in the stop

state exceeded the setting.

742 RIGID TAP ALARM : LSI OVER

FLOW

During rigid tapping, an LSI overflow occurred on the spindle side.
