APPENDIXG. ALARM LIST

B–63524EN/01

870

No. DescriptionFaulty location and remedy

SPM in-

dica-

tion(*1)

Message

7n07 SPN_n_ : OVERSPEED 07 Check for a sequence error. (For ex-

ample, check whether spindle syn-

chronization was specified when the

spindle could not be turned.)

The motor speed has exceeded

115% of its rated speed.

When the spindle axis was in position

control mode, positional deviations

were accumulated excessively (SFR

and SRV were turned off during

spindle synchronization.)

7n09 SPN_n_ : OVERHEAT

MAIN CIRCUIT

09 1 Improve the heat sink cooling sta-

tus.

2 If the heat sink cooling fan stops,

replace the SPM unit.

Abnormal temperature rise of the

power transistor radiator

7n11 SPN_n_ : OVERVOLT

POW CIRCUIT

11 1 Check the selected PSM.

2 Check the input power voltage and

change in power during motor de-

celeration. If the voltage exceeds

253 VAC (for the 200–V system) or

530 VAC (for the 400–V system),

improve the power supply imped-

ance.

Overvoltage of the DC link section of

the PSM was detected. (PSM alarm

indication: 7)

PSM selection error. (The maximum

output specification of the PSM is ex-

ceeded.)

7n12 SPN_n_ : OVERCUR-

RENT POW

CIRCUIT

12 1 Check the motor insulation status.

2 Check the spindle parameters.

3 Replace the SPM unit.

The motor output current is abnormal-

ly high.

A motor–specific parameter does not

match the motor model.

Poor motor insulation

7n15 SPN_n_ : SP SWITCH

CONTROL

ALARM

15 1 Check and correct the ladder se-

quence.

2 Replace the switching MC.

The switch sequence in spindle

switch/output switch operation is ab-

normal.

The switching MC contact status

check signal and command do not

match.

7n16 SPN_n_ : RAM FAULT 16 Replace the SPM control printed cir-

cuit board.

Abnormality in an SPM control circuit

component is detected. (RAM for ex-

ternal data is abnormal.)

7n18 SPN_n_ : SUMCHECK

ERROR PGM

DATA

18 Replace the SPM control printed cir-

cuit board.

Abnormality in an SPM control circuit

component is detected. (Program

ROM data is abnormal.)

7n19 SPN_n_ : EX OFFSET

CURRENT U

19 Replace the SPM unit. Abnormality in an SPM component is

detected. (The initial value for the U

phase current detection circuit is ab-

normal.)

7n20 SPN_n_ : EX OFFSET

CURRENT V

20 Replace the SPM unit. Abnormality in an SPM component is

detected. (The initial value of the V

phase current detection circuit is ab-

normal.)

7n21 SPN_n_ : POS SENSOR

POLARITY ER-

ROR

21 Check and correct the parameters.

(No. 4000#0, 4001#4)

The polarity parameter setting of the

position sensor is wrong.
