MAINTENANCE

B–63524EN/01

1. METHOD OF REPLACING BATTERY

817

When the battery voltage falls, APC alarms 306 to 308 are displayed on

the screen. When APC alarm 307 is displayed, replace the battery as soon

as possible. In general, the battery should be replaced within one or two

weeks of the alarm first appearing. This, however, depends on the number

of pulse coders being used.

If the battery voltage drops any further, the current positions for the pulse

coders will be lost. Turning on the power to the control unit in this state

results in APC alarm 300 (reference position return request alarm) being

issued. Return the tool to the reference position after replacing the battery.

So, FANUC recommends replacing the battery every year concerning

without the alarm occurring.

The battery for the built–in absolute pulse coder is connected with the

servo amplifier.

Note that the attachment methods of the battery and ordering

specifications of battery are different from SERVO AMPLIFIER a series

(SVM) to SERVO AMPLIFIER b series.

Replace the battery only while the power to the servo unit is on. If the

battery is replaced while the power is off, all of the absolute position

settings will be lost.

Replacement procedure is as follows.

1. Turn the servo unit (machine) on.

2. Place the machine in the emergency stop state.

3. Confirm that the servo motors are not active.

4. In case of SERVO AMPLIFIER a series, confirm that the LED that

indicates DC link charging status is not light.

5. Remove the battery and replace the battery.

6. The replacement is complete. Turn the servo unit (machine) off.

WARNING

D The power magnetic cabinet in which the servo units are

mounted has a high–voltage section. Don’t touch this

section that presents a severe risk of the electric shock.

D In case of SERVO AMPLIFIER a series, replace the battery

after confirm that the LED that indicates DC link charging

status is not light. Charged DC link has a high–voltage.

D Ensure that the replacement battery is of the correct type.

Otherwise, heat, explosion or ignition will occur. Always use

the specified battery.

D Pay careful attention to the polarity of the battery. Fault

polarity may be the cause of heat, explosion or ignition.

Also, it may be the cause of lost of the absolute position in

the pulse coder.

D Attach the socket to unused connector of CX5X or CX5Y.

These sockets that protect the connectors are attached to

these connectors in shipping from FANUC. If connector pins

of CX5X or CX5Y will short, heat, explosion or ignition will

occur. Also, it may be the cause of lost of the absolute

position in the pulse coder.

1.5

BATTERY FOR

BUILT–IN ABSOLUTE

PULSE CODERS

(DC6V)

Replacement procedure
