Series 16i/18i/160i/180i - TB Operators manual Page 61

Operators manual
PROGRAMMING
B–63524EN/01
2. CONTROLLED AXES
35
The increment system consists of the least input increment (for input ) and
least command increment (for output). The least input increment is the
least increment for programming the travel distance. The least command
increment is the least increment for moving the tool on the machine. Both
increments are represented in mm, inches, or degrees.
The increment system is classified into IS–B and IS–C (Tables 2.3 (a) and
2.3 (b)). Select IS–B or IS–C using bit 1 (ISC) of parameter 1004. When
the IS–C increment system is selected, it is applied to all axes and the 1/10
increment system option is required. The setting of parameter ISC (No.
1004#4) is valid for all axes. When IS–C is selected, for example, the
setting units for all axes are IS–C.
Table 2.3 (a) Increment system IS–B
Least input increment Least command increment
Metric mm 0.001 mm (Diameter) 0.0005 mm
system
machine
input
0.001 mm (Radius) 0.001 mm
machine
0.001 deg 0.001 deg
inch 0.0001 inch (Diameter) 0.0005 inch
input
0.0001 inch (Radius) 0.001 inch
0.001 deg 0.001 deg
Inch mm 0.001 mm (Diameter) 0.00005 mm
machine
system
input
0.001 mm (Radius) 0.0001 mm
system
0.001 deg 0.001 deg
inch 0.0001 inch (Diameter) 0.00005 inch
input
0.0001 inch (Radius) 0.0001 inch
0.001 deg 0.001 deg
Table 2.3 (b) Increment system IS–C
Least input increment Least command increment
Metric mm 0.0001 mm (Diameter) 0.00005 mm
system
machine
input
0.0001 mm (Radius) 0.0001 mm
machine
0.0001 deg 0.0001 deg
inch 0.00001 inch (Diameter) 0.00005 inch
input
0.00001 inch (Radius) 0.0001 inch
0.0001 deg 0.0001 deg
Inch mm 0.0001 mm (Diameter) 0.000005 mm
machine
system
input
0.0001 mm (Radius) 0.00001 mm
system
0.0001 deg 0.0001 deg
inch 0.00001 inch (Diameter) 0.000005 inch
input
0.00001 inch (Radius) 0.00001 inch
0.0001 deg 0.0001 deg
2.3
INCREMENT SYSTEM
