Beta i SVPM Descriptions Additional Manual Page 34

Additional Manual
5.TOTAL CONNECTION DIAGRAMA-72562EN-027
- 33 -
5.3.3.2 Detail of cable K12
CNC JA7A
(3) (1)SOUT SIN1
JA7B SVPM
(1)
(3)SIN SOUT1
(12),(14),(16)
0V 0V (12),(14),(16)
(2)
(4)*SIN *SOUT1
(4) (2)*SOUT *SIN1
Ground
plate
Ground
plate20 pin half pitch connector 20 pin half pitch connector
Note)
Cable specification: 0.09 mm
2
twisted pair with common shielded
Recommended cable (wire only): A66L-0001-0284#10P
See Section 5.4.1 for details of connectors applied to recommended cable.
NOTE
If cable K12 is installed near the likes of a power cable, its shielding
wire must be connected to a grounding plate. If an SVPM is installed
near the CNC, however, it is not necessary to connect the shielding
wire to a grounding plate.
