Series 30i-MODEL A, External Data Input Additional Manual Page 11

Additional Manual
A-79227E
Title
Draw
No.
Ed. Date Design Description
Date Jan.09.’04 Design. Apprv.
9/22
Page
FANUC Series 30i-MODEL A
External Data Input
NOTE
1 The external program number search is available when
parameter ESR(No.6300#4) is set to “1”.
2 In reset state the automatic operation lamp is off. If the start
button is pushed in the cycle operation stop or hold state,
search execution starts from the actual position indicated by
the pointer.
3 When there is no program stored in memory corresponding to
the set program number, the alarm DS0059 occurs.
4 When the program number search is set to 0, the alarm
DS0059 occurs.
5 Data for the external program number search is accepted
regardless of the mode, but the search execution can be
made only in the reset state. Therefore, in case that the PMC
sequence, which the cycle start is executed by checking
search completion signal for external data input only, is used,
if the external program number search is commanded twice,
the program is executed twice.
( When CNC accepts a command of the program number
search, the command is not cancelled even if CNC becomes
reset state by external reset signal and so on.) (See Fig.
1.2(a))
If the program execution after reset becomes a problem,
please make the PMC sequence not to execute the cycle
start after reset.
