FANUC Series 30i-MODEL A
External Data Input
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
6300 EEX ESR ESC
[Input type] Parameter input
[Data type] Bit path
# 3 ESC When a reset is input between input of the external data input read signal
ESTB and execution of a search, the external program number search
function:
0 : Performs a search.
1 : Does not perform a search.
# 4 ESR External program number search
0 : Disabled
1 : Enabled
# 7 EEX PMC EXIN function
0 : Conventional specifications
1 : Extended specifications
If you want to handle unavailable data with the PMC/EXIN command
according to the conventional specifications, such as an shift value is up to
+/- 10000 in the external machine zero point shift, set this bit to 1.
To use this function for multi-path control, the setting for the first path
(main) is used. The EXIN specifications cannot be changed for each path.
For details of EXIN and how to change ladder software, refer to the PMC
specifications and other manuals.
#7 #6 #5 #4 #3 #2 #1 #0
6301 EED NNO EXM EXA
[Input type] Parameter input
[Data type] Bit machine group
# 0 EXA This bit selects an external alarm message specification.
0 : A message number from 0 to 999 can be sent. The CNC adds 1000 to an
alarm number for distinction from general alarms.
1 : A message number from 0 to 4095 can be sent. The CNC prefixes the
character string "EX" to an alarm number for display.
